Pneumatic Fittings Description

• Pneumatic Union

Brand: Uflow

• Model: Equal Union VO21, Reducing Union VO22
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Applicable Tube Size (OD): 4mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm

• Pneumatic Union Elbow

Brand: Uflow

• Model: Equal Union VO23, Reducing Union VO24
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: Equal: 4mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm; Unequal: 8mm x 12mm

• Pneumatic Union Tee

Brand: Uflow

• Model: Equal Union VO25, Reducing Union VO26
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: Equal: 4mm, 6mm, 8mm, 10mm, 12mm; Unequal: 4mm x 6mm, 6mm x 8mm, 8mm x 10mm

• Pneumatic Union Y

Brand: Uflow

• Model: Equal Union VO27, Reducing Union VO28
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: Equal: 4mm, 6mm, 8mm, 10mm, 12mm; Unequal: 4mm x 6mm, 6mm x 8mm, 8mm x 10mm

• Pneumatic Male Connector

Brand: Uflow

• Model: VO29
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: 4mm, 6mm, 8mm, 10mm, 12mm
• Thread Size: 1/8″, 1/4″, 3/8″, 1/2″
• Connection: Male BSP/NPT/BSPT Thread

• Pneumatic Female Connector

Brand: Uflow

• Model: VO30
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: 4mm, 6mm, 8mm, 10mm, 12mm
• Thread Size: 1/8″, 1/4″, 3/8″, 1/2″
• Connection: Female BSP/NPT/BSPT Thread

• Pneumatic Male Elbow

Brand: Uflow

• Model: VO31
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: 4mm, 6mm, 8mm, 10mm, 12mm
• Thread Size: 1/8″, 1/4″, 3/8″, 1/2″
• Connection: Male BSP/NPT/BSPT Thread

• Pneumatic Male Tee

Brand: Uflow

• Model: VO36
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: 4mm, 6mm, 8mm, 10mm, 12mm, 14mm
• Thread Size: 1/8″, 1/4″, 3/8″, 1/2″
• Connection: Male BSP/NPT/BSPT Thread

• Pneumatic Cross Union

Brand: Uflow

• Model: VO37
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: 4mm, 6mm, 8mm, 10mm, 12mm

• Pneumatic Flow Control Valve

Brand: Uflow

• Model: VO38
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: 4mm, 6mm, 8mm, 10mm, 12mm

• Pneumatic Male Y

Brand: Uflow

• Model: VO40
• Media: Air
• Max. Operating Pressure: 10 Bar
• Ambient Temperature: -10°C to +60°C
• Media Temperature: +5°C to +50°C
• Applicable Tube Material: Nylon, Polyurethane
• Size: OD: 4mm, 6mm, 8mm, 10mm, 12mm; Thread Size: 1/8″, 1/4″, 3/8″, 1/2″

Key Features:

• Compact & Captivating Design: Space-efficient and visually appealing.
• Full Bore Piping: Ensures smooth and unobstructed fluid flow.
• Air-Tight Sealing: Provides reliable and leak-proof connections.
• Compatibility: Suitable for use with both Nylon and Polyurethane (PU) pipes.
• Durable & Maintenance-Free: Designed for longevity with minimal maintenance.
• Robust Collet Design: Ensures stable fitment and functionality, even under vibration.
• Easy Installation: Quick and simple tube connection through manual plugging, with easy disconnection by pressing the plastic collet cap.

Applications:

These pneumatic fittings are versatile for a range of compressed air applications, including:

• Pneumatic Cylinders: Compatible with all types.
• Compressed Air Lines: Ideal for use in machinery and systems where pneumatic applications are employed.
• Directional Control Valves (DCV), Solenoid Valves (SOV), and Other Valves: Provides reliable integration.
• Pneumatic Control & Circuit Panels: Facilitates efficient control and management.
• Air Preparation Units (FRL): Works well with filters, regulators, and lubricators for effective air preparation.
